SAW Filter for GPS

Technical Data of SAW Filter for GPS
Model Center frequency (MHz) Max. insertion loss Band width Ripple Min. stopband attenuation Group delay Delay ripple (p-p) Package
SBP35AS6 35.42MHz 20dB 2MHz/3dB 0.8dB 40dB 1550μs ±20ns SMD1365
SJKF42A3 42.0MHz 10dB 2.75MHz/1dB 1.0dB 40dB 1200μs ±20ns SMD1365
SJKF52A4 51.9MHz 20dB 4MHz/3dB 0.8dB 40dB 1800μs ±150ns SMD1365
SJKF63AS6 63.5MHz 17dB 12MHz/3dB 0.8dB 40dB 860μs ±20ns SMD1365
SJKF65A10 65.0MHz 22dB 10MHz/1dB 1.0dB 40dB 940μs ±20ns SMD1365
SJKF66A2 66.22MHz 22dB 2MHz/3dB 0.8dB 40dB 1800μs ±150ns SMD1365
SJKF70A1 70.0MHz 16dB 1.0MHz/1.5dB 1.0dB 45dB 1000μs ±20ns SMD1365
SJKF70A305 70.0MHz 15dB 3.5MHz/1.5dB 1.0dB 45dB 1000μs ±20ns SMD1365
SJKF80A1 80.0MHz 12dB 1MHz/1dB 1.0dB 40dB 940μs ±20ns SMD1365
SJKF105A205 105.0MHz 12dB 2.8MHz/1dB 1.0dB 40dB 1000μs ±20ns SMD1365
SJKF1575 1575.42MHz 1.6dB 2.4MHz/1dB 0.5dB 45dB 25μs ±10ns DCC6C
Size
SAW Filter for GPS
