SAW Filter for Satellite Receiver

Technical Data of SAW Filter for Satellite Receiver
Model Center frequency Typical 3dB bandwidth Max. insertion loss Package
SJKF480A 480MHz 22KHz 18dB F-11
SJKF480A 480MHz 16.5KHz 18dB TO-39
SJKF480-1 480MHz 21.5KHz 18dB TO-39
SJKF480-2 480MHz 21.5KHz 27dB TO-39
SJKF480-3 480MHz 24KHz 36.2dB TO-39
SJKF480-4 480MHz 22.5KHz 27.5dB TO-39
SJKF480-5 480MHz 23/23.5KHz 15/27dB TO-39B
SJKF480-6 479.5MHz 22.1/22.5KHz 18/27dB TO-39B
SJKF480-7 479.5MHz 22/27.5KHz 26.8/53.6dB TO-39B
SJKF480-8 480MHz 24KHz 36.2dB TO-39
SJKF4816 480MHz 24.5KHz 16dB TO-399B
